Product Description
THE MOST BLOW FOR YOUR DOUGH
The Shocker XL 2 gallon train horn kit will blow you away with its price and sound! This is the best value we have for a full Shocker XL based kit. If you are asking yourself "what's the loudest horn you make?" and also "what's the best value for the money?" you've just found the answer.
- The Loudest kit we make, be heard for miles!
- Includes a 2-gallon tank, compressor and all necessary hardware
- 4-Second honk time, 65-second recovery.
- The Shocker horns in the kit are backed by our lifetime manufacturer's warranty. All other items would be covered per standard warranty guidelines (1 year)
Please note: The 6 horn upgrade kit does NOT include the extension brackets to connect to our STDK bracket or Shocker XL horn mount.
CUSTOMER VIDEO REVIEW OF THESE HORNS
- High-efficiency & extremely loud
- Stainless steel diaphragms won't rust!
- Manifold-less design for flexible installation
- All-inclusive train air horn solution!
- Heavy-duty compressor for faster fills!
- All standard mounting hardware
- Max honk time: 4 to 6 seconds
- It can be heard from miles away!
THIS KIT INCLUDES THE FOLLOWING:
- Shocker S4 train horns
- 2 Gallon air tank
- Air Compressor
- 110/150 PSI Pressure switch w/ 40 Amp Relay
- Spare Air Filters
- 10 ft of 5/16 in D.O.T. approved Air line
- 17 ft of 1/2 in D.O.T. approved Air line
- 17 ft of red 10 gauge power wire
- 17 ft of grey 18 gauge power wire
- 17 ft of blue 18 gauge power wire
- 1/2 in NPT electric solenoid valve
- HornBlasters 200 PSI air gauge
- Brass NPT fittings kit including safety valve and blow-off
- Wiring & plumbing kit
- Mounting hardware
- Detailed instructions
SPECIFICATIONS
- Part Number: HK-S4-2HB
- Horn: Shocker 4 train horn kit
- Material: High-impact ABS
- Horn Measurements
â„– 1 19.50″ (495.30 mm) â„– 2 16.25″ (412.75 mm) â„– 3 14.75″ (374.65 mm) â„– 4 12.75″ (323.85 mm) - Flare: 5″ (127 mm)
- Weight: 4.5 lb (2.04 Kg)
- Fitting Size: â…›″ M NPT
- Tank: HornAir 2 gallon tank
- Tank Length: 17" (431.8 mm)
- Tank Diameter: 6" (152.4 mm)
- Tank Height: 7" (177.8 mm) (With Legs)
- Tank Weight: 10 lb (4.54 Kg)
- Working Pressure: 150 PSI
- Compressor Length: 8.75" (222.25 mm)
- Compressor Width: 4" (101.6 mm)
- Compressor Height: 6.6" (167.64 mm)
- System Max Amp Draw: 25 Amps
2-GALLON AIR TANK DIMENSIONAL DRAWING
INSTRUCTIONS
WARNINGS & NOTICES
HEARING PROTECTION REQUIRED
This product produces extreme loudness. Proper hearing protection must be worn at all times during its operation. Hearing loss or permanent damage may result from unsafe use. Use this product in a safe and responsible manner and at a distance of at least 100 meters from others. Never operate this product in a closed environment, in close proximity to living beings, or where prohibited by law.
WARNING
This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.p65warnings.ca.gov.
